Amplifier unit, DIN-rail mount type Laser Sensor Keyence IL-1000
Amplifier unit, DIN-rail mount type Laser Sensor
Keyence IL-1000
Keyence IL-1000
Amplifier unit, DIN-rail mount type
Laser Sensor
Keyence IL-1000
| Model | IL-1000 | |
| Type | DIN-rail mount | |
| DIN-rail mount | Main unit | |
| Head compatibility | Compatible | |
| Display | Minimum displayable unit |
IL-030: 1 µm, IL-065/IL-100: 2 µm, IL-300: 10 µm, IL-600: 50 µm, IL-2000: 100 µm |
| Display range | IL-030/IL-065/IL-100: ±99.999 mm to ±99 mm (4 levels selectable), IL-300/IL-600: ±999.99 mm to ±999 mm (3 levels selectable), IL-2000: ±9999.9 mm to ±9999 mm (2 levels selectable) |
|
| Display rate | Approx. 10 times/sec. | |
| Analog voltage output | ±5 V, 1 to 5 V, 0 to 5 V Output impedance 100 Ω*1 | |
| Analog current output | 4 to 20 mA Maximum load resistance of 350 Ω*1 | |
| Control input | Bank switch input | Non-voltage input*2 |
| Zero-shift input | ||
| Stop emission input | ||
| Timing input | ||
| Reset input | ||
| Control output | Judgement output | Open collector output (NPN, PNP changeover possible/N.O., N.C. changeover possible)*3 |
| Alarm output | Open collector output (NPN, PNP changeover possible/N.C.)*3 | |
| Current | Power voltage | 10 to 30 VDC ripple (P-P) 10% included, Class 2*4 |
| Power consumption | 2300 mW or less (at 30 V: 77 mA or less) | |
| Environmental resistance | Pollution degree | 2 |
| Ambient temperature | -10 to +50 °C 14 to 122 °F (No condensation or freezing) | |
| Relative humidity | 35 to 85 % RH (No condensation) | |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z directions | |
| Material | Case / Front sheet: Polycarbonate; Key tops: Polyacetel; Cable: PVC | |
| Weight | Approx. 150 g (including attachments) | |
| *1 Select and use one of ±5 V, 1 to 5 V, 0 to 5 V or 4 to 20 mA. *2 Assign an input of your choice to the 4 external input lines before using. *3 The NPN open collector rated output is: 50 mA max./ch (20 mA when adding an expansion unit) less than 30 V, residual voltage less than 1 V (less than 1.5 V when adding over 6 units including the main unit) The PNP open collector rated output is: 50 mA max./ch (20 mA/ch when adding expansion units), less than power voltage, and less than 2 V residual voltage (less than 2.5 V when adding over 6 units including the main unit) *4 If there are over 6 additional expansion units, please use a power voltage of 20 to 30 V. |
||
