Sensor
| General Data | |
|---|---|
| Nominal Current IN | 4 A |
| Nominal Voltage UN | 250 V |
| Number of Positions | 4 |
| Volume Resistance | ≤ 5 mΩ |
| Insulation Resistance | ≥ 100 MΩ |
| Length of Cable | See Listing |
| Stripping Length of the Free Conductor End | 50 mm |
| Ambient Temperature (Operation) | -25 ... 90 °C |
| General Characteristics | |
| Coding | A-standard |
| Surge Voltage Category | II |
| Pollution Degree | 3 |
| Degree of Protection | IP65/IP67/IP68 |
| Contact Material | CuSn |
| Contact Surface Material | Ni/Au |
| Contact Carrier Material | TPU GF |
| Material of Grip Body | TPU, hardly inflammable, self-extinguishing |
| Material, Knurls | Zinc die-cast, (nickel-plated) |
| Sealing Material | NBR |
| Status Display | No |
| Conductor Data | |
| Cable Type | PUR halogen-free black |
| Cable Abbreviation | Li9Y11Y-HF |
| Conductor Cross Section | 0.34 mm² |
| AWG Signal Line | 22 |
| Conductor Structure, Signal Line | 42x0.10 mm |
| Core Diameter Including Insulation | 1.27 mm ±0.02 mm |
| Thickness, Insulation | Approx. 0.21 mm (Core Insulation) |
| External Cable Diameter | 4.70 mm |
| Wire Colors | Brown, white, blue, black |
| External Sheath, Color | Black-gray RAL 7021 |
| Nominal Current IN | 4 A |
| Nominal Voltage UN | 250 V |
| Number of Positions | 4 |
| Volume Resistance | ≤ 5 mΩ |
| Insulation Resistance | ≥ 100 MΩ |
| Length of Cable | See Listing |
| Stripping Length of the Free Conductor End | 50 mm |
| Ambient Temperature (Operation) | -25 ... 90 °C |
| General Characteristics | |
| Coding | A-standard |
| Surge Voltage Category | II |
| Pollution Degree | 3 |
| Degree of Protection | IP65/IP67/IP68 |
| Contact Material | CuSn |
| Contact Surface Material | Ni/Au |
| Contact Carrier Material | TPU GF |
| Material of Grip Body | TPU, hardly inflammable, self-extinguishing |
| Material, Knurls | Zinc die-cast, (nickel-plated) |
| Sealing Material | NBR |
| Status Display | No |
| Conductor Data | |
| Cable Type | PUR halogen-free black |
| Cable Abbreviation | Li9Y11Y-HF |
| Conductor Cross Section | 0.34 mm² |
| AWG Signal Line | 22 |
| Conductor Structure, Signal Line | 42x0.10 mm |
| Core Diameter Including Insulation | 1.27 mm ±0.02 mm |
| Thickness, Insulation | Approx. 0.21 mm (Core Insulation) |
| External Cable Diameter | 4.70 mm |
| Wire Colors | Brown, white, blue, black |
| External Sheath, Color | Black-gray RAL 7021 |
| Insulation Resistance | ≥ 100 MΩ*km |
| Conductor Resistance | ≤ 58 Ω/km |
| Nominal Voltage, Conductor | 300 V |
| Test Voltage, Conductor | 3000 V |
| Overall Twist | 4 wires, twisted |
| Outer Sheath, Material | PUR |
| Material Conductor Insulation | PP |
| Conductor Material | Bare Cu litz wires |
| Cable Weight | 30 kg/km |
| Smallest Bending Radius, Movable Installation | 47 mm |
| Number of Bending Cycles | 4,000,000 |
| Bending Radius | 47 mm |
| Traversing Path | 10 m |
| Traversing Rate | 3 m/s |
| Acceleration | 10 m/s² |
| Ambient Temperature (Operation) | -40 ... 80 °C (cable, fixed installation) -5 ... 80 °C (cable, flexible installation) |
| Special Properties | Flexible cable conduit capable, Silicone-free, Free of substances which would hinder coating with paint or varnish |
| Flame Resistance | As per UL-Style 20549 |
| Halogen-Free | As per DIN VDE 0472 part 815 |
| Resistance to Oil | Complying with DIN EN 60811-2-1 |
| Other Resistance | Highly resistant to acids, alkaline solutions and solvents, Hydrolysis and microbe resistant |
