ESD Polyimide Film Tape
- PME 8998 is a black polyimide film-backed silicone adhesive tape used for PCB solder masking and other high temperature applications and insulation.
Masking for golden finger of PCB in wave soldering & reflow process
Features
- Leaves no residue
- High electric insulation performance
- Resistant high temperature up to 280℃.
- Excellent tensile strength & Elongation.
- RoHS Compliant.
Typical Physical Properties and Performance Characteristics
|
Item Black Heat Resistant Tape |
Typical Value |
Test Method |
|
Backing |
0.025mm |
/ |
|
Total Thickness |
0.055±0.005mm |
/ |
|
Adhesion to Steel |
≥4N/25mm |
GBT 2792-2014 |
|
Tensile Strength |
≥2.0(KN/M) |
GBT 30776-2014 |
|
Elongation |
≥10% |
|
|
Surface Resistance |
104-109ohms |
/ |
|
Static Discharge |
<100V |
/ |
|
Operating Temperature |
280℃ |
5min Testing to Stainless steel plate |
Product Construction/Material Description
|
Part No. |
Description |
Length/m |
Width/mm |
|
PME7412B0333 |
ESD Polyimide Adhesive Tape |
33 |
3 |
|
PME7412B0433 |
ESD Polyimide Adhesive Tape |
33 |
4 |
|
PME7412B0533 |
ESD Polyimide Adhesive Tape |
33 |
5 |
|
PME7412B0733 |
ESD Polyimide Adhesive Tape |
33 |
7 |
|
PME7412B0933 |
ESD Polyimide Adhesive Tape |
33 |
9 |
|
PME7412B1033 |
ESD Polyimide Adhesive Tape |
33 |
10 |
|
PME7412B1233 |
ESD Polyimide Adhesive Tape |
33 |
12 |
|
PME7412B1433 |
ESD Polyimide Adhesive Tape |
33 |
14 |
|
PME7412B1533 |
ESD Polyimide Adhesive Tape |
33 |
15 |
|
PME7412B1733 |
ESD Polyimide Adhesive Tape |
33 |
17 |
|
PME7412B1933 |
ESD Polyimide Adhesive Tape |
33 |
19 |
|
PME7412B2033 |
ESD Polyimide Adhesive Tape |
33 |
20 |
|
PME7412B2233 |
ESD Polyimide Adhesive Tape |
33 |
22 |
|
PME7412B2533 |
ESD Polyimide Adhesive Tape |
33 |
25 |
|
PME7412B3033 |
ESD Polyimide Adhesive Tape |
33 |
30 |
|
PME7412B4033 |
ESD Polyimide Adhesive Tape |
33 |
40 |
|
PME7412B5033 |
ESD Polyimide Adhesive Tape |
33 |
50 |
