Sensor
Specifications
|
Model |
FU-16Z*1 |
|||
|
Optical axis diameter |
ø2.5 mm0.098" |
|||
|
Beam emitting direction |
Side |
|||
|
Aperture angle |
Approx 6° |
|||
|
Fibre unit length |
2 m78.74" free-cut |
|||
|
Fibre unit diameter |
ø1.0 |
|||
|
Minimum bend radius |
R2 mm0.079" Tough-Flex |
|||
|
Minimum detectable object |
Object with a diameter of 0.1 mm0.004"*2 |
|||
|
Environmental resistance |
Ambient temperature |
-40 to +50 °C -40 to 122 °F |
||
|
Weight |
Approx. 8 g |
|||
|
*1 For details on the detecting distance, see the fiber amplifier catalog. |
||||
