Fixed-quantity Pneumatic Screw Feeder Ohtake BS-D Type

Fixed-quantity Pneumatic Screw Feeder BS-D Type

Delivering screws with pneumatic tube
Suitable for manual assembly applications

Pneumatic mechanism for efficient screw feeding
Helps to improve working cycle takt time; applicable for steel screws.

Compact size, with maximum size of 1300cc storage available

Providing precise number of screws
Quantitative supplies for manual application, with easily accessible counter panel.





Supported screw diameter (mm)	Main component type
	BS Series		BS-R Series	BS-D Series	BS-C Series
	Scooping chamber capacity: approx. 280cc	Scooping chamber capacity: approx. 1300cc	-	-	Scooping chamber capacity: approx. 280cc	Scooping chamber capacity: approx. 1300cc
2.0	BS-S20	BS-L20	BS-R20	-	BS-CS20	BS-CL20
2.3	BS-S23	BS-L23	BS-R23	-	BS-CS23	BS-CL23
2.6	BS-S26	BS-L26	BS-R26	-	BS-CS26	BS-CL26
3.0	BS-S30	BS-L30	BS-R30	BS-D30	BS-CS30	BS-CL30
3.5	BS-S35	BS-L35	BS-R35	BS-D35	BS-CS35	BS-CL35
4.0	BS-S40	BS-L40	BS-R40	BS-D40	BS-CS40	BS-CL40
5.0	BS-S50	BS-L50	BS-R50	BS-D50	BS-CS50	BS-CL50
6.0	BS-S60	BS-L60	-	BS-D60	BS-CS60	BS-CL60

• Product name：BS-D
• Dimensions：169(W)×436(D)×270(H)
• Total weight (with rail) ：Approx. 10kgf
• Power supply：AC100～240V DC15V 1A AC adapter included
• Overload protection：-
• Output signal：-
• Brush overload prevention：-
• Screw size：M2.0～M3.0　｜　M3.5～M5.0
• Screw length：Up to 18㎜
• Capacity：Approx. 150cc
• Accessories：Operation Manual, AC Adapter, hex wrench, adjustment driver
