Components & Accessories
SPECIFICATIONS
Operating frequency(mechanical):120 Operation / mim
Operating frequency(electrical):
10~30 Operation / mim
Insulation resistance(at 500 VDC)
100M Ω(Min)
Service life(mechanical)
Min. 10,000,000 Operations
Service life(electrical)
Min. 6,000 Operations
RATING
0.1A 125 VAC, 1A/5A 125/250VAC ; 0.1A 30VDCAPPLICATION
TV Game,Vending Machine,Coin-op Phone Pin-Ball GameDIMENSIONS
CONTACT CONFIGURATION
OPERATING FORCE
ORDER INFORMATION
OPERATING CHARACTERISTICS
