Manual Screw Feeder Ohtake NSBC Type

Manual Screw Feeder NSBC Type

Counter available for displaying number of screws picked up
Automatic alarm notification when preset number of screws have been used

With settable counter for pick-up screw count
Can display up to 99 screws/cycle, and 9999 pickup cycles



Supported screw diameter (mm)	Main component type			Swap rail set type
	NSB Series	NSR Series	NSBC Series	NSB Series	NSR Series	NSBC Series
1.0	NSB-10	NSR-10	NSBC-10	SR10SET	SRR10SET	SR10SET
1.2	NSB-12	NSR-12	NSBC-12	SR12SET	SRR12SET	SR12SET
1.4	NSB-14	NSR-14	NSBC-14	SR14SET	SRR14SET	SR14SET
1.7	NSB-17	NSR-17	NSBC-17	SR17SET	SRR17SET	SR17SET
2.0	NSB-20	NSR-20	NSBC-20	SR20SET	SRR20SET	SR20SET
2.3	NSB-23	NSR-23	NSBC-23	SR23SET	SRR23SET	SR23SET
2.6	NSB-26	NSR-26	NSBC-26	SR26SET	SRR26SET	SR26SET
3.0	NSB-30	NSR-30	NSBC-30	SR30SET	SRR30SET	SR30SET

• Product name：NSBC
• Dimensions：123(W)×181(D)×145(H)
• Total weight (with rail)： Approx. 3.2kgf
• Power supply：AC100～240V DC15V 1A AC adapter included
• Overload protection：-
• Output signal：-
• Screw size：M1.0～M3.0
• Screw length：Up to 20㎜
• Capacity：Approx. 80cc
• Accessories：Operation Manual, AC Adapter, hex wrench, adjustment driver, 0.35㎜ gauge plate
