SPECIFICATIONS
Operating frequency(electrical):Max. 120 Operation / mim
Contact resistance:
500m Ω(max)
Insulation resistance(at 500 VDC)
100M Ω(Min)
Dielectric strength(50 - 60 Hz)
Min. 500VAC RMS
Service life(electrical)
150,000~300,000 Operations
Degree Of Protection
IP67 (excluding the terminals on terminal models)
※ For IP67 option, please contact your ZIPPY
sales representative.
RATING
50mA 16VDC; 100mA 12VDC; 1mA 5VDCAPPLICATION
1. Automobilesdetection of door opening and closing and shift lever position etc.
2. Household appliances
propane stoves, vacuum cleaners, washing machines, air conditioners etc.
DIMENSIONS
CONTACT CONFIGURATION
ORDER INFORMATION
TERMINAL TYPES
OPERATING CHARACTERISTICS
