Components & Accessories
SPECIFICATIONS
Operating frequency(electrical):Max. 120 Operation / mim
Contact resistance:
500m Ω(max)
Insulation resistance(at 500 VDC)
100M Ω(Min)
Dielectric strength(50 - 60 Hz)
Min. 500VAC RMS
Service life(electrical)
150,000~300,000 Operations
RATING
50mA 16VDC; 100mA 12VDC; 1mA 5VDCAPPLICATION
1. Automobilesdetection of door opening and closing and shift lever position etc.
2. Household appliances
propane stoves, vacuum cleaners, washing machines, air conditioners etc.
DIMENSIONS
ORDER INFORMATION
