Sensor
Mechanics/electronics
Performance
Interfaces
Ambient data
Classifications
| Supply voltage Vs | DC 18 V ... 30 V 1) |
| Ripple | < 5 Vpp 2) |
| Power consumption | < 7 W |
| Enclosure rating | IP67 |
| Protection class | III |
- 1) Limit values, reverse-polarity protected.
- 2) May not exceed or fall below Uv tolerances.
Performance
| Speed measuring range | 3 m/min ... 4,800 m/min |
| Accuracy | ± 0.05 % 1) |
| Output time | 20 ms |
| Light source | Laser, infrared |
| Laser class |
3B (IEC 60825-1:2014) EN 60825-1:2014 |
| Typ. light spot size (distance) | 2 mm x 2.5 mm (240 mm) |
| Reading distance | 240 mm, ± 10 mm |
| Angle between laser beams | Approx. 3° |
- 1) Accuracy of measurement; at length from 5 m: 1 σ, from 10 m: 2 σ, from 20 m: 3 σ.
Interfaces
|
|||||
|
|||||
Ambient data
| Electromagnetic compatibility (EMC) |
EN 61000-6-2 (2006-03) EN 61000-6-4 (2007-09) |
| Ambient temperature operation | +10 °C ... +45 °C 1) |
| Ambient temperature, storage | –25 °C ... +75 °C 2) |
| Vibration resistance | DIN/EN 60068-2-6, DIN/EN 60068-2-64 |
| Shock resistance | DIN/EN 60068-2-27 |
- 1) May not fall short of or exceed VS tolerances.
- 2) Max. 95 % humidity, non-condensing.
Classifications
| ECl@ss 5.0 | 27270890 |
| ECl@ss 5.1.4 | 27270890 |
| ECl@ss 6.0 | 27270890 |
| ECl@ss 6.2 | 27270890 |
| ECl@ss 7.0 | 27270890 |
| ECl@ss 8.0 | 27270890 |
| ECl@ss 8.1 | 27270890 |
| ECl@ss 9.0 | 27270890 |
| ECl@ss 10.0 | 27270890 |
| ECl@ss 11.0 | 27270890 |
| ETIM 5.0 | EC001825 |
| ETIM 6.0 | EC001825 |
| ETIM 7.0 | EC001825 |
| UNSPSC 16.0901 | 39121528 |
