SPECIFICATIONS
Operating frequency(mechanical):120 Operation / mim
Operating frequency(electrical):
10~30 Operation / mim
Contact resistance:
100m Ω(max)
Insulation resistance(at 500 VDC)
100M Ω(Min)
Service life(mechanical)
Min. 1,000,000 Operations
Service life(electrical)
1A/3A-Min.10,000 Operations
RATING
0.1A/1A/3A 125VAC; 3A 5VDC/12VDCAPPLICATION
‧ Computer mouse‧ Joysticks
‧ Charger unit for mobile phone
‧ Detection of key position for automobiles
‧ Small home appliances
‧ Central heating control
‧ Electronic Door Locks
‧ Smart Meter
DIMENSIONS
CONTACT CONFIGURATION
OPERATING FORCE
ORDER INFORMATION
TERMINAL TYPES
OPERATING CHARACTERISTICS
