SPECIFICATIONS
Operating frequency(mechanical):120 Operation / mim
Operating frequency(electrical):
10~30 Operation / mim
Contact resistance:
100m Ω(max)
Insulation resistance(at 500 VDC)
100M Ω(Min)
Service life(mechanical)
Min. 1000000 Operations
Service life(electrical)
1A/3A-Min.10,000 Operations
RATING
0.1A/1A/3A 125VAC ; 1A/3A 250VAC; 1A 24VDC; 3A 12VDCAPPLICATION
1. Computer mouse2. Joysticks
3. Charger unit for mobile phone
4. Detection of key position for automobiles
5. Small home appliances
6. Central heating control
7. Electronic Door Locks
8. Smart Meter
DIMENSIONS
CONTACT CONFIGURATION
OPERATING FORCE
ORDER INFORMATION
TERMINAL TYPES
OPERATING CHARACTERISTICS
