Components & Accessories
SPECIFICATIONS
Operating frequency(mechanical):120 Operation / mim
Operating frequency(electrical):
10~30 Operation / mim
Contact resistance:
100m Ω(max)
Insulation resistance(at 500 VDC)
100M Ω(Min)
Service life(mechanical)
Min. 10,000,000 Operations
Service life(electrical)
3A~15A-Min. 10,000 Operations
RATING
0.1A/3A/6A/10A/15A/16(4) 125/250VAC ; 0.1A 30VDCAPPLICATION
Joystick,TV Game,Time Recorder,Air Conditioner,Food Processor,Juice Maker,Alarm,Mixer,Shredder MachineDIMENSIONS
CONTACT CONFIGURATION
.png "DW-contact (4)")
OPERATING FORCE
ORDER INFORMATION
TERMINAL TYPES
OPERATING CHARACTERISTICS
