Screwing
New Standard Series Electric Screwdriver
- The whole machine adopts non-contact switch, which has longer life and lower maintenance rate
- Three-stage forward and reverse switch, feel better, effectively prevent wrong operation
- Brushless motor, torque output is more stable, suitable for use in dust-free working environment
New Standard Series Electric Screwdriver
Features
Optional specification of screwdriver bits
Features
- The whole machine adopts non-contact switch, which has longer service life and lower maintenance rate. The three-stage forward and reverse switch has better hand feeling and effectively prevents incorrect operation.
- No carbon brush motor, the torque output is more stable, suitable for use in a dust-free working environment, high stability, simple operation, the screwdriver can be used for a long time.
- Using non-contact switch, no need to replace consumables, long service life.
| Model | Measuring Range | No load speed(r.pm) | Input voltage | Weight(g) | Diameter of screw | Screw bit | ||
|---|---|---|---|---|---|---|---|---|
| Kgf.cm | N.m | HI | LO | |||||
| SD-BA200L | 0.1-1.5 | 0.01-0.15 | 1000 | 800 | 30V | 340 | M1.0-M1.7 | Ø 4mm |
| SD-BA300L | 0.2-3.5 | 0.02-0.34 | M1.2-M2.5 | |||||
| SD-BA400L | 0.3-6.5 | 0.03-0.63 | M1.4-M2.6 | |||||
| SD-BA450L/P | 1-10 | 0.1-1 | 540 | M1.4-M3.0 | Ø 5mm | |||
| SD-BA450LF/PF | 2000 | 1600 | ||||||
| SD-BA500L/P | 2-12 | 0.2-1.18 | 1000 | 800 | M1.6-M3.0 | |||
| SD-BA500LF/PF | 2000 | 1600 | ||||||
| SD-BA550L/P | 3-19 | 0.2901.89 | 1000 | 800 | M2.3-M3.5 | |||
| SD-BA600L/P | 5-25 | 0.502.45 | 680 | M2.6-M4.0 | 1/4 hex | |||
| SD-BA600LF/PF | 5-23 | 0.5-2.25 | 2000 | 1600 | ||||
| SD-BA620L | 10-30 | 0.98-2.94 | 1000 | 800 | M2.6-M4.5 | |||
| SD-BA620LF | 2000 | - | M2.6-M4.5 | |||||
| SD-BA630L/P | 10-35 | 0.98-3.43 | 650 | 450 | M3.0-M5.0 | |||
| SD-BA700L/P | 15-45 | 1.47-4.41 | M3.5-M5.5 | |||||
| SD-BA730L | 20-50 | 1.96-4.9 | 1000 | - | M4.0-M6.0 | |||
Optional specification of screwdriver bits
